Antenna Multiplexers and filters
MULTIPLEXER UHF-VHF/FM MAST
Discontinued Product
Kod 9020040
Model MM-207
Seriler 902
Description
Multiplexers for masts, universal or by bands, of two inputs. They mix the signals from several antennas in a single coaxial cable. They incorporate switchable DC paths to permit the feeding of a preamplifier.
Applications
Individual digital and analogue terrestrial TV installations. In installations where the reception levels are adequate (60 to 75 dBµV) the signals of all the antennas can be combined to distribute them in the building with a single coaxial cable.
Characteristics
Shielded zamak chassis, covered by an ABS plastic box for outdoor use. Fixed to the mast by means of a polyamide clamp. F-type connectors. Supplied in individual or multiple packs.
Accessories
9120039 CM-004 Male F connector for Ø6.6mm coaxial. 9080023 MC-302 Male F connector for RG-6 coaxial, Ø7.0 mm
